| Specification | Details |
|---|---|
| Product Model | 24H2F Pro |
| INNOCN Model | 24D1F Pro |
| Panel Type | IPS |
| Curvature | Flat |
| Aspect Ratio | 16:9 |
| Screen Size | 23.8 inch |
| Active Area (H x V) | 527.04 x 296.46 mm |
| Resolution | 1920 x 1080 (FHD) |
| Refresh Rate | 100Hz |
| Backlight Type | ELED |
| Brightness (Typical) | 250 cd/m² |
| Default Color Temperature | 7000K |
| Static Contrast Ratio | 1000:1 |
| Dynamic Contrast Ratio | Million-level |
| Color Depth | 16.7M (6-bit + FRC) |
| sRGB Color Gamut | 99.0% |
| DCI-P3 Color Gamut | 93.0% |
| Adobe RGB Color Gamut | 81% (CIE 1931), 88% (CIE 1976) |
| Viewing Angle (H/V) | 178°/178° |
| Response Time (GtG) | 14ms |
| Overdrive Response Time (GtG) | 4ms |
| HDMI 1.4 | 1 (Max 100Hz) |
| DisplayPort 1.2 | 1 (Max 100Hz) |
| USB Type-C | 1 (Max 15W PD, Max 100Hz) |
| Audio Out | 1 |
| Input Voltage | 12V DC |
| Power Supply Type | External Adapter |
| Power Consumption (Typical/Max) | 20W / 42W |
| Standby Power Consumption | ≤0.5W |
| Power Indicator | On: White, Power Saving: Red |
| Color | Black |
| Black Border Width | 3.5mm |
| Dimensions (with Stand) | 542.4 x 403.8 x 160.9 mm |
| Dimensions (without Stand) | 542.4 x 334.5 x 38.5 mm |
| Package Dimensions | 615 x 405 x 108 mm |
| Net Weight (with Stand) | 3.2 kg |
| Net Weight (Panel Only) | 2.5 kg |
| Gross Weight | 4.5 kg |
| VESA Mount | 75 x 75 mm (Requires adapter) |
| Tilt Angle | Forward 5°, Backward 15° |
| Control Method | Joystick / INNOCN OSD |
| OSD Language | Multi-language |
| Variable Refresh Rate | AdaptiveSync |
| Key Features | Color Temp adjustment, Hardware Low Blue Light, Scenario Modes, DCR, Flicker-free, Overdrive |
| Included Accessories | HDMI Cable x1, Power Adapter, User Manual, Screwdriver |
| Certifications | 3C, TUV Low Blue Light, Energy Efficiency |
